S-PL-4
SAFETY PLAN FOR BRIDGE PIERS IN CLEAR ZONE
(Click image to open PDF)
Lastest Revision Note
01/09/2024 ADDED GENERAL NOTE (E) AND NOTES ON THE PLAN VIEW FOR STANDARD DRAWINGS S-SSMB-4 AND S-SSMB-6D. REVISED GENERAL NOTES, SECTION A-A, PLAN VIEW AND DESCRIPTION.
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| S-GRT-2P | EARTH PAD FOR TYPE 38 TERMINAL | FOR ADDITIONAL GRADING REQUIREMENTS AT END TERMINAL |
| S-GRT-2R | SAFETY PLAN: MINIMUM INSTALLATION AT BRIDGE ENDS | EARTH PAD FOR TYPE 38 (RETROFIT) |
| S-SSMB-2 | 51" SINGLE SLOPE CONCRETE BARRIER WALL | FOR ADDITIONAL DETAILS INCLUDING ALTERNATE REINFORCEMENT |
| S-SSMB-6 | SAFETY PLAN AT SIDE ROADS OR PRIVATE DRIVES | GUARDRAIL ATTACHMENT TO SINGLE SLOPE CONCRETE BARRIER WALL |
| STD-1-2 | STEEL SLIDER PLATE ASSEMBLIES FOR CONCRETE PARAPET AND BRIDGE DECK DRAIN DETAILS 1993 | PROVIDE PARAPET OPENINGS @ EVERY 75’ FOR DRAINAGE |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 303-01 | TON | MINERAL AGGREGATE, TYPE A BASE, GRADING D | |
| 604-03.07 | C.Y. | CLASS A CONCRETE (DESCRIPTION) | |
| 705-06.20 | EACH | TANGENT ENERGY ABSORBING TERM MASH TL-3 | |
| 705-06.25 | EACH | THRIE BEAM BRIDGE TRANSITION MASH TL-3 | |
| 711-05.71 | L.F. | 51IN SINGLE SLOPE CONCRETE BARRIER WALL |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 07-11-2013 | 04-11-2014 | 02-05-2016 | 10-10-2016 | 06-28-2019|01-09-2024 |
